Steel has remained expensive for years, prompting procurement teams to move beyond unit price when sourcing fasteners. Although a single bolt may contain only a fraction of a cent’s worth of base material, its true cost once accounting for scrap generated during manufacturing can be substantially higher. Crucially, the decisive factor is rarely the alloy grade or supplier margin; rather, it is the manufacturing process itself.
When a plant selects between cold heading and CNC turning, it simultaneously determines the amount of steel scrap generated per part. Two facilities may produce identical M8 hex bolts and pay the same price for raw steel, yet arrive at markedly different material costs: one process removes metal to achieve the final geometry, while the other reshapes metal with minimal removal. This article quantifies that yield gap in practice, explains its root causes, and demonstrates how to calculate tangible cost savings before implementing a process change.
Cold forming and CNC turning both begin with the same raw idea, a length of wire or bar stock, but they treat that material in opposite directions.
In cold forming, also called cold heading, a machine cuts a precise slug from wire and then displaces it through a sequence of dies. The metal is squeezed, extruded, and reshaped, yet none of it leaves the part as waste. The slug is sized so its volume matches the finished component.
CNC turning works the other way. A lathe grips a bar and spins it against a cutting tool that peels material away until the target shape remains. Everything the tool removes becomes chips, and chips are scrap the moment they fall into the bin.
That single contrast, rearrange the metal instead of removing it, is the root of the entire material efficiency story.
Cold forging depends on a property engineers describe as volume constancy. At room temperature, steel behaves as nearly incompressible, so its density stays effectively constant while it deforms. When a wire slug is pressed into a die cavity, the metal flows to fill every corner of the shape rather than being carved off.
Because the volume is conserved, the cut-off slug can be calculated to match the final part volume with high accuracy. The only routine loss is a small trim at the head, which is minor and often recoverable. No cutting tool means no chip stream, and no chip stream means the raw material input maps almost one to one onto the finished fastener.
This is the reason cold forming material efficiency sits close to the theoretical maximum. The process does not fight the metal. It cooperates with the physics of the material.
The yield gap becomes obvious once you examine part geometry. A fastener with a head significantly wider than its shank is the worst case for turning. To turn that head from bar stock, the plant must begin with a diameter equal to the head and then machine the shank down, discarding the difference as swarf. Depending on the head to shank ratio, turned parts commonly lose 40 to 70 percent of the starting bar as chips.
Cold heading inverts that relationship. The slug is cut to the part volume, and the head is upset from the same material. Reported material utilization for cold formed fasteners typically reaches the high 90s percent, with the only loss coming from the cut-off trim and a small amount of flash.
So the comparison is not subtle. For a standard bolt, cold forming can approach near complete material usage, while CNC turning may return only 30 to 60 percent of the bar into the finished product and sends the rest to scrap. The exact figure depends entirely on the part’s shape.
Translating a yield gap into money is straightforward. Begin with the steel price per kilogram, multiply by the scrap rate, and then multiply by your annual production volume measured in part weight.
Annual waste cost equals steel price per kilogram times scrap mass per part times annual volume. Scrap mass per part is the finished weight divided by yield minus that same finished weight. In plain terms, a lower yield means you must buy more steel to ship the same number of good parts.
Consider a plant running ten million M8 bolts a year. If CNC turning delivers a 50 percent yield, half the purchased steel ends up as chips. At a modest steel price, that discarded material represents a six figure annual loss that never appears on the part quote because it is buried inside the process selection. Cold heading removes most of that loss, and the saving flows directly to margin.
Cold heading wins on waste, but it is not universal. Three situations keep CNC turning as the right call.
Prototypes and short development runs rarely justify the tooling lead time of a multi-station former. Turning a few hundred samples on a lathe validates the design without committing to dies.
Ultra complex geometry is the second case. Parts with deep internal bores, asymmetric features, or tight concentricity across many axes may exceed what cold forming can hold repeatably.
Low volume specialty production is the third. When annual demand sits in the thousands rather than the millions, the setup and die cost of cold forming cannot be spread across enough parts to pay back, and turning stays competitive even with its scrap.
The goal is to match the process to the volume and the shape, not to declare one method superior in every case.
Many production lines do not pick one process. They combine both.A common strategy forms the blank on a cold heading machine and then moves it to a CNC lathe or thread roller for the critical details. The former delivers the bulk geometry at near zero scrap, while the lathe handles only the tight tolerance features that forming cannot reach. This hybrid path captures most of the material saving from cold forming while keeping the precision that turning provides.
For high volume fasteners, even a partial hybrid, such as forming the head and then machining a single datum face, can recover the majority of the waste reduction benefit at a fraction of the tooling investment.
Every kilogram of steel turned into chips required mining, smelting, and rolling before it ever reached the shop floor. When that material is discarded as swarf, the embedded energy and emissions deliver no value to the customer. Cold forming’s near complete utilization means less ore extracted, less steel rolled, and less scrap to collect, recycle, or landfill per finished fastener.
For manufacturers answering customer audits or internal ESG targets, process selection becomes a practical lever. Shifting high volume parts from turning to cold forming can reduce the material footprint of a product line without changing its performance, and the sustainability report improves alongside the profit margin.
Before recommending a process change, build the estimate from your own numbers rather than a vendor claim. Use these variables.
Define the finished part weight in grams. Define the current process yield as a decimal, for example 0.5 for turning at 50 percent. Define the cold forming yield, often close to 0.97 to 0.99. Define the steel price per kilogram and the annual volume.
The scrap saved per part equals finished weight multiplied by the difference between one divided by current yield and one divided by cold forming yield. Multiply that by annual volume to reach total scrap saved in kilograms, then multiply by steel price for the annual saving. This framework stays honest because it uses your real yield and your real price. It does not assume a fixed percentage, and the result scales directly with how much you actually produce.
Process choice is material strategy. For high volume fasteners, cold heading and CNC turning lead to very different scrap profiles, and the volume constancy principle explains why cold forming keeps almost all the steel in the part. The financial and environmental case grows directly with annual volume, which makes the calculation worth running on your own numbers.
Cold heading reshapes a cut slug by displacing metal into a die, while CNC turning removes material from a bar as chips. The former keeps nearly all the raw material in the part, and the latter discards a large share as scrap.
The saving depends on part geometry. Turned fasteners with a wide head often return only 30 to 60 percent of the bar as product, whereas cold formed parts commonly reach the high 90s percent utilization. The gap narrows for long thin shafts and widens for headed parts.
Volume constancy means steel keeps a constant volume during cold deformation because it is nearly incompressible. The metal flows to fill the die instead of being cut away, so the slug volume matches the finished part and almost no chip is generated.
No. For prototypes, very low volumes, and parts with complex internal geometry, the tooling and die cost of cold forming can outweigh its material saving. Turning stays competitive when the annual quantity is too small to spread the setup cost.
Yes. A hybrid line forms the blank on a cold header and then machines only the critical features on a lathe. This captures most of the material efficiency while preserving the precision that turning provides.
Explore the DBHP-6 and DBHP-8 product pages to see full specifications, or contact the Dongrui team for a process recommendation based on your part geometry and annual volume.
